Ceramic Fiber Board
Keywords:
Ceramic Fiber Board
Classification:
- Details
-
Ceramic Fiber board is manufactured in a wet forming process using Ceramic Fiber bulk and binders. Ceramic Fiber board is designed for insulation applications experiencing vibration, mechanical stress and erosive forces. Ceramic Fiber board can reduce energy costs and cycling times due to high insulating capability, as well as serving to protect refractory surfaces from thermal shock and chemical attack.
Features
● Excellent thermal shock resistance
● Can be machined, cut and shaped easily
● High rigidity and light weight
● Low thermal conductivity
● Low heat storage
Typical Applications
● Furnace hot face lining in petrochemical furnace
● Furnace hot face lining in ceramic kiln
● Board over blanket hot face lining
● Back-up insulation to brick & castable
● Expansion joints
Typical Parameters
Description CCFR STD BOARD CCFR HA BOARD CCFR HZ BOARD Classification Temperature (℃） 1260 1350 1430 Color White White White Density (kg/m3) 280--360 300--360 300--360 Modules of Rupture (Mpa) ≥0.3 ≥0.3 ≥0.3 Compressive Strength
(Mpa, 10% relative deformation)0.25/0.3 0.25/0.3 0.25/0.3 Loss of lgnition (%) ≤6 ≤6 ≤6 Permanent Linear Shrinkage 1000℃x24h≤3.0 1200℃x24h≤3.5 1350℃x24h≤3.5 Thermal Conductivity (W/m.K) 400℃ 0.08 0.07 0.17 600℃ 0.11 0.10 0.09 800℃ 0.14 0.13 0.13 1000℃ 0.19 0.19 0.18
Quality Control
SHANDONG HIKING INTERNATIONAL COMMERCE GROUP CO.LTD Founded in 2002. our company is located in Qingdao city, Shandong Province.It has developed into one of the largest manufacturers of refractory fibers in Asian areas through many years struggle. At present, our factory has more than 600 employees with total areas of nearly 50.000 ㎡. We can produce all kinds of Ceramic Fiber Products such as Ceramic Fiber Blanket, Ceramic Fiber Board, Ceramic Fiber Paper, Ceramic Fiber Bulk, Ceramic Fiber Module etc. with annual capacity of more than 8 thousand tons.
Packing & Shipping
In the recent years’ development,we are owning eighteen of ceramic fiber blanket production linese sixteen lines are spun ceramic fiber type,two is blown ceramic fiber type;one process vacuum form ceramic fiber products line;two ceramic fiber module lines;one ceramic fiber paper line. At the same time, our factory has been keeping touch with the most authoritative technical research centers for many years, we are improving ourselves in production all the time, such as the new products’creation, manufacturing design , after-sale service.
Relying on consummate manufacturing technology and abundant technical power which is the guarantee of product quality, our company has passed 9001:2000 Quality Management System Attestation in advanced the other company.
Our products are sold to many foreign countries suchas :KOREA,JAPAN,USA,SAUDIARABIA, UK, GERMANY, TURKEY,PK,MALAYSIA,DUBAI,CHILE,VIETNAM and SWITERLAND etc.we also had continuously developed new products and strengthened after-sales service in metallurgy, electric power, petroleum, chemical industry as well as many other fields, greatly meeting market demand.
