Rock Wool Board
Keywords:
Rock Wool Board
Classification:
- Details
-
Rock wool board for industry has a certain strength, the fiber structure of which makes itself have the properties of good dimensional stability, thermal stability and chemical stability, and also have another three characteristics of excellent hear resistance, corrosion resistance and low thermal conductivity.
Its fireproof performance reaches class A1.
Aluminum foil and other facing materials can be attached on the fire layers.
Product Name Rock Wool Board Density(kg/m³ ) 60 80 100 120 180 Thickness(mm) 30-150 Size(mm) 1200×600 Properties Unit Density(kg/m³) 60 80 100 120 180 Thermal conductivity(average 25℃) wf(m. k) ≤0.040 ≤0.038 ≤0.038 ≤0.038 ≤0.038 Combustion performance Class-Al non-combustible Hydrophobic rate % ≥99 ≥99 ≥99 ≥99 ≥99 The maximun temperature ℃ 550 650 750 750 750 Recommend service temperature ℃ 450 550 650 650 650 Thermal shrinkage temperature under load ℃ 500 650 650 650 650 Linear shrinkage ratio % ≤2 ≤2 ≤2 ≤2 ≤2 Corrosiveness No corrosion
Quality Control
SHANDONG HIKING INTERNATIONAL COMMERCE GROUP CO.LTD Founded in 2002. our company is located in Qingdao city, Shandong Province.It has developed into one of the largest manufacturers of refractory fibers in Asian areas through many years struggle. At present, our factory has more than 600 employees with total areas of nearly 50.000 ㎡. We can produce all kinds of Ceramic Fiber Products such as Ceramic Fiber Blanket, Ceramic Fiber Board, Ceramic Fiber Paper, Ceramic Fiber Bulk, Ceramic Fiber Module etc. with annual capacity of more than 8 thousand tons.
Packing & Shipping
In the recent years’ development,we are owning eighteen of ceramic fiber blanket production linese sixteen lines are spun ceramic fiber type,two is blown ceramic fiber type;one process vacuum form ceramic fiber products line;two ceramic fiber module lines;one ceramic fiber paper line. At the same time, our factory has been keeping touch with the most authoritative technical research centers for many years, we are improving ourselves in production all the time, such as the new products’creation, manufacturing design , after-sale service.
Relying on consummate manufacturing technology and abundant technical power which is the guarantee of product quality, our company has passed 9001:2000 Quality Management System Attestation in advanced the other company.
Our products are sold to many foreign countries suchas :KOREA,JAPAN,USA,SAUDIARABIA, UK, GERMANY, TURKEY,PK,MALAYSIA,DUBAI,CHILE,VIETNAM and SWITERLAND etc.we also had continuously developed new products and strengthened after-sales service in metallurgy, electric power, petroleum, chemical industry as well as many other fields, greatly meeting market demand.
