Calcium Silicate Board
Keywords:
Calcium Silicate Board
Classification:
- Details
-
The main constituents of 1000℃ calcium silicate insulation board is Xonotlite and reinforced glass fibre,no asbestos. It is a kind of high efficient energy-saving material with temperature limited 1050 cent-degree. Characterized by low bulk density, high specific strength, superior heat resistance,outstanding thermal insulation,excellent durability, chemical corrosion resistance, easy to be cut by saw and easy installation, calcium silicate can be widely used for the insulation of industrial kiln.
Physical And Chemical Microstructure ,Production,Technology
The main constituent Sonotlite is synthesized through dynamic hydrothermal process using quartz and lime as raw material.. The microstructure crystal looks like a hollow cactus ball and make the board has superior features,unique and irreplaceable.
A.Low thermal conductivity figures—provides top insulation thoughout its temperature range.
B.Good thermal stability—withstand continuous heat up to its full temperature use limit with small linear shrinkage.
C.Light bulk density—low heat storage
D.High mechanical strength— specific strength superior other shaped insulations and retains full integrity at elevated temperatures(excellent creep –resistance).
E.Long service life—no pulverization such like ceramic fibre felt.
F.Safe and clean operation—Free from asbestos,suiphur,and chloride, no toxic carcinogen.
Areas of application
A.Cement industry: preheaters and cyclone separators, decomposition kiln,tertiary air duct and cooler
B.Nonferrous metallurygical industry: aluminum power calciner and electrolysis groove
C.Petrochemical industry: Splitting furnace,catalytic cracking furnace,petroleum pipeline,underground heat-flooding
D.Metallurgical industry(steel plant): hot-rolling heat furnace,cool-rolling mill set,RH vacuum degassing furnace , smelters,hot deformation and heat treatment plants
E.Power plant:preheat stove ,pipe
F.Glass industry:melting furnace and recuperator,annealing furnace and cooling channels
G.Ceramic industry: chamber and tunnel furnace
Typical Parameters
Physical performance
ItemsUnit LG Standard GB/T10699-2015 CCFR-23 CCFR-25 Bulk Density Kg/m3 230
(±10%）250
(±10%）≤220,≤270 Flexural Strength Mpa ≥0.50 ≥0.55 ≥0.30 Thermal Conductive W/m.k ≤0.056 +0.00011tt ≤0.058 +0.00011tt ≤0.060 (100℃) Temp Limit ℃ 1000 1000 1000 Linear Shrinkage % ≤2
(1000℃,16hrs)≤2
(1000℃,16hrs)≤2
(1000℃,16hrs)
Quality Control
SHANDONG HIKING INTERNATIONAL COMMERCE GROUP CO.LTD Founded in 2002. our company is located in Qingdao city, Shandong Province.It has developed into one of the largest manufacturers of refractory fibers in Asian areas through many years struggle. At present, our factory has more than 600 employees with total areas of nearly 50.000 ㎡. We can produce all kinds of Ceramic Fiber Products such as Ceramic Fiber Blanket, Ceramic Fiber Board, Ceramic Fiber Paper, Ceramic Fiber Bulk, Ceramic Fiber Module etc. with annual capacity of more than 8 thousand tons.
Packing & Shipping
In the recent years’ development,we are owning eighteen of ceramic fiber blanket production linese sixteen lines are spun ceramic fiber type,two is blown ceramic fiber type;one process vacuum form ceramic fiber products line;two ceramic fiber module lines;one ceramic fiber paper line. At the same time, our factory has been keeping touch with the most authoritative technical research centers for many years, we are improving ourselves in production all the time, such as the new products’creation, manufacturing design , after-sale service.
Relying on consummate manufacturing technology and abundant technical power which is the guarantee of product quality, our company has passed 9001:2000 Quality Management System Attestation in advanced the other company.
Our products are sold to many foreign countries suchas :KOREA,JAPAN,USA,SAUDIARABIA, UK, GERMANY, TURKEY,PK,MALAYSIA,DUBAI,CHILE,VIETNAM and SWITERLAND etc.we also had continuously developed new products and strengthened after-sales service in metallurgy, electric power, petroleum, chemical industry as well as many other fields, greatly meeting market demand.
